Ultra fun - Inc. Screws, covers, cases.

The Flyer foil is designed to assist your first wing flights, while not limiting your development. Its smooth take-off, stability, control and predictability make it the ideal foil for learning to fly easily. 100% carbon.

Features:

Easy take-off
Full Carbon Construction
Lightweight and maintenance-free
Plug & Play with complete compatibility with AFS EVO Range

DIMENSIONS

Front foil Flyer
________________________________________
Surface (cm2) 1500 | 1800
Span (mm) 955 | 1050
Aspect Ratio 6.3 | 6.3
Cord max (mm) 185 | 205
Thickness max (mm) 20 | 22
Fuselage size -
Construction HR Carbon / Corecell
Weight (kg) TBA | TBA
Screw size M8x20mm Torx 45

Stabiliser
________________________________________
Surface (cm2) 245
Span (mm) 450
Aspect Ratio 8.3
Cord max (mm) 66.8
Thickness max (mm) 8.3
Construction Carbone prepreg
Weight (kg) 0.2
Screw size M6x16mm
Compatibility All AFS fuselage

HR Carbon Mast
________________________________________
Length (cm) 80
Cord min (mm) 135
Thickness min (mm) 16
Screw size (mast/fuselage) M8x40mm
Construction HR Carbon
Weight (kg) 1,6
Compatibility All AFS FUSELINK foils

Fuselage Evo
________________________________________
Length 68 cm
Construction Carbone prepreg
Compatibility All Fuselink/stabs masts
PROGRAM
Wing foil/SUP foil beginner to experienced freeride/SUP foiler

The Kit:

The Flyer Pack is supplied with its protective padded covers and its screw kit to mount front foil, stab to mast and fuselage, as well as nuts and screws to mount foil to board - includes Y shaped Torx Key driver.

Warranty:

All AFS Flyer/EVO products come with a 2 year warranty, subject to our fair usage policy.

Tech specs:

All Carbon components 100% Made in France.

Table of use/Tech Spec in photos for more details.

* Weight Tolerance: +/- 8%. All information contained in this web page is subject to change and alteration at any time without notice.

Mast/Fuselage compatible with the following Foils (wings)

Front wing:

Carver 1250
Carver 1500
Carver 1750
Carver 2000
Flyer 850
Flyer 1000
Flyer 1300
Performer 950
Performer 1250
Performer 1450
Performer 1650
Performer 1900

Rear Wing (Stab):

Tracer 200
Tracer 250
Tracer 310
Tracer 440
Performer S160
Performer S190
Performer RS230
Performer RS260
